M-Audio 2-In/4-Out Audio MIDI Interface [AIR 192|8]

Description

Key Features

• 24-bit/192kHz resolution for professional recording and monitoring
• Hi-Speed USB circuitry for fastest connection, with class-leading round-trip latency of 2.59ms*
• Transparent Crystal™ preamps and ultra-pristine A/D converters for unsurpassed audio recording quality
• VU LED meters for dialing in the perfect level
• Flexible inputs: (2) XLR+¼” TRS combo with -10dB mic pad or ¼” instrument inputs
• Use any combination of TRS combo or ¼” instrument input on the two channels:(2) TRS, (2) instrument or (1) of each
• MIDI input/output for connecting virtually any external MIDI gear
• Stereo ¼” and RCA outs with direct mono/stereo switch
• (2) RCA assignable auxiliary outputs; ¼” headphone output with independent source and level controls
• Rugged metal chassis; large central control for easy volume adjustment
• USB/Direct knob for balancing between the input signal and the computer signal

*Round trip latency is dependent on buffer settings, and computer hardware

Downloads

• AIR 192-8 User Guide v1.1

What’s In The Box

• AIR 192|8
• USB-C-to-USB-C Cable
• USB-C-to-USB-A Cable
• (2) 1/8″ (3.5 mm) to MIDI Adapters
• Software Download Cards
• User Guide
• Safety and Warranty Manual

Specifications



Minimum System Requirements

macOS: 10.8 Class Compliant

PC: Windows 7, Windows Driver

Standard USB 2.0 or USB-C Port

Mic Inputs 1-2 (balanced XLR)
FREQUENCY RESPONSE	20Hz – 20kHz (+/-0.1 dB)
DYNAMIC RANGE	104dB (A-weighted)
SIGNAL-TO-NOISE RATIO	104dB (+1.0dBu, A-weighted)
THD+N	0.001% (1kHz, +0.8dBu, -1dBFS)
PREAMP EIN	-126dBu (150Ω, unweighted)
MAX INPUT LEVEL	+1.8dBu
GAIN RANGE	60dB



Line Input 1-2 (balanced 1/4″ TRS)
FREQUENCY RESPONSE	20Hz – 20kHz (+/-0.1dB)
SIGNAL-TO-NOISE RATIO	101dB (1kHz, +4dBu, A-weighted)
THD+N	0.002% (1kHz, +19.7dBu, -1dBFS)
MAX INPUT LEVEL	+20.7dBu
DYNAMIC RANGE	106dB (A-weighted)



Inst Input 1-2 (unbalanced 1/4″ TS)
FREQUENCY RESPONSE	20Hz – 20kHz (+/-0.1dB)
DYNAMIC RANGE	106dB (A-weighted)
SIGNAL-TO-NOISE RATIO	98dB (+4dBu, A-weighted)
THD+N	0.001% (1kHz, +5.8dBu, -1dBFS)
MAX INPUT LEVEL	+6.8dBu
INPUT IMPEDANCE	~1MΩ
GAIN RANGE	24dB



Main TRS Outputs, 1/L & 2/R (balanced 1/4″ TRS)
FREQUENCY RESPONSE	20Hz – 20kHz (+/-0.1dB)
DYNAMIC RANGE	109dB (A-weighted)
THD+N	0.003% (1kHz, -1dBFS)
MAX OUTPUT LEVEL	+13dBu



Main & Aux RCA Outputs 1 – 4 (Unbalanced RCA)
FREQUENCY RESPONSE	20Hz – 20kHz (+/-0.1dB)
DYNAMIC RANGE	109dB (A-weighted)
THD+N	0.003% (1kHz, -1dBFS)
MAX OUTPUT	+7dBu



Headphone Outputs (Stereo 1/4″ TRS)
DYNAMIC RANGE	101dB
THD+N	0.008% (1kHz, -1dBFS, 36mW)
MAX POWER	36mW (32-ohm load)
MIN IMPEDANCE	32-ohm
